Titanium Castings
Khoom siv: CP Titanium (Qib 2), Titanium Aluminium Vanadium Alloy Ti-6Al-4V (Qib 5), los yog Customized
Muaj nuj nqi
Khoom siv: | CP Titanium (Qib 2), Titanium Aluminium Vanadium Alloy Ti-6Al-4V (Qib 5), los yog Customized |
Qhov Loj: | Raws li kos duab |
Titanium Castings Description
Titanium alloy muaj kev ua haujlwm zoo, yog cov khoom siv zoo heev, thiab siv dav. Txawm li cas los xij, tus nqi ua haujlwm ntawm titanium alloy yog qhov tsawg, cov khoom tsis yooj yim rau tshuab, thiab cov nqi ua haujlwm siab. Los ntawm cov txheej txheem casting, tshwj xeeb tshaj yog precision casting, qhov chaw nrog cov duab nyuaj tuaj yeem tsim ncaj qha, tshem tawm ntau cov txheej txheem machining, thiab nce kev siv cov ntaub ntawv mus txog ze li 90 feem pua.
Titanium Qib 2 yog lub teeb yuag thiab tiv taus corrosion heev. Nws yog ib qho titanium uas tsis yog khoom siv thiab suav tias yog "kev lag luam ntshiab" titanium (TiCP). Ua tsaug rau nws qhov kev siv tau ntau yam thiab muaj dav, Qib 2 yog siv rau hauv feem ntau ntawm cov tshuaj ua cov nroj tsuag thiab yog txias formable. Qib 2 phaj thiab ntawv tuaj yeem muaj lub zog tensile kawg ntawm thiab siab dua 40, 000 psi.
Nrog rau nruab nrab lub zog thiab zoo heev corrosion kuj, nws kuj muaj ductility thiab siab cuam tshuam toughness, thiab zoo weldability. Nws yog siv feem ntau nyob rau hauv daim ntawv thov uas yuav tsum tau welding. Qib 2 tsis yog hardenable los ntawm kev kho cua sov.
Cam khwb cia titanium alloys feem ntau muab faib ua "alloys", "(ntxiv) alloys", thiab "alloys" raws li theem muaj pes tsawg leeg, thiab tseem muab faib ua cam khwb cia high-strength, tshav kub-resistant, thiab corrosion-resistant titanium alloys los ntawm convention. Ntawm lawv, casting Ti-6Al-4V (Qib 5) yog dav siv casting titanium alloys, uas yog yus muaj los ntawm nruab nrab lub zog, kub kuj, corrosion kuj, thiab zoo yas. Nws yog tshwj xeeb tshaj yog haum rau aerospace engines thiab structural castings.
Titanium Qib 5 yog feem ntau siv Titanium thoob ntiaj teb.
Titanium Qib 5 yog alloyed nrog 6 feem pua Aluminium thiab 4 feem pua Vanadium thiab feem ntau hu ua Ti 6Al-4V. Qib 5 lossis Ti 6Al-4V, suav txog 50 feem pua ntawm tag nrho cov titanium siv thoob ntiaj teb.
Nws tuaj yeem kho cua sov los txhim kho cov khoom siv kho tshuab. Nws tuaj yeem siv rau hauv welded fabrication ntawm kev pabcuam kub txog li 315 degree. Cov alloy no muaj lub zog siab ntawm lub teeb yuag, muaj txiaj ntsig formability thiab siab corrosion kuj.
Cam khwb cia titanium alloy muaj qhov sib npaug qhov kawg lub zog li cam khwb cia hlau alloy tab sis muaj hauv qab cov yam ntxwv zoo dua.
● Qhov ceev ntawm tsuas yog 4.5, qis dua piv nrog 7.8 rau hlau;
● Thaum tshav kub kub tsis kam mus txog 400 degree / 500 degree;
● Ntau dua corrosion kuj;
● Bio-compatibility (tsis muaj kev tsis lees paub los ntawm tib neeg lub cev)
Titanium alloys yog melted nyob rau hauv lub tshuab nqus tsev skull furnaces thiab yuav cam khwb cia rau ntau lub npe ntawm cov twj tso kua mis, valve impellers, dag pob qij txha, thiab tshuab ntawm lwm yam duab. X-ray tshuaj xyuas yog siv nyob rau hauv tag nrho cov txheej txheem casting raws li kev tsim khoom zoo. SSC tuaj yeem tsim kev cai titanium precision castings raws li koj cov duab kos thiab specifications.
Taw qhia txog txoj kev Casting
● Machined graphite pwm casting:
Txoj kev no tuaj yeem ua kom yooj yim molding thiab tswj tau zoo ntawm metallurgical zoo. Thicker thiab loj loj castings tuaj yeem ua tiav los ntawm txoj kev no.
● Ceramic pwm peev casting:
Txoj kev no ua rau cov castings meej dua, nrog cov ntsiab lus xws li cov logos kom meej meej cam khwb cia. Qhov loj-loj thiab cov duab zoo tuaj yeem raug cam khwb cia zoo siv txoj kev no.
Kev kho deg rau Titanium Castings
Corrosion Resistance thiab Surface Treatment | 1) atmospheric oxidation kev kho mob |
Hnav Resistance Surface Treatment | 1) ntub txheej |
Tom qab ntawd Surface Treatment | 1) nto tiav |
Titanium Fastener Daim ntaub ntawv thiab lwm yam lag luam
● Tus Tsav Tsheb Golf
● Impeller & Blisk
● Motocycle Parts
● Cov Khoom Siv Khoom
● Valve
● Kub Barrier
● Aerospace
● Tub rog
● Tshuaj
● Cov kev pabcuam roj av
● Kho mob
● Marine
● Cov cuab yeej tes
● Cov khoom siv ncaws pob
● Kev ua haujlwm siab tsheb
● Aerospace
● Zog
● Kev tsim khoom
Titanium Physical Properties
Qib | Qhov kawg Tensile Strength | Yield zog | Elongation feem pua | Txo Cheeb Tsam feem pua | Qhov xwm txheej | ||
KSI | MPa | KSI | MPa | ||||
1 | 35 | 240 | 20 | 138 | 24 | 30 | Raws li teev (zoo) |
2 | 50 | 345 | 40 | 275 | 20 | 30 | Raws li teev (zoo) |
3 | 64 | 450 | 55 | 380 | 18 | 30 | Raws li teev (zoo) |
4 | 80 | 550 | 70 | 483 | 15 | 25 | Raws li teev (zoo) |
5 | 130 | 895 | 120 | 828 | 10 | 25 | Raws li teev (zoo) |
6 | 115 | 792 | 110 | 758 | 10 | 25 | Forged Bars |
7 | 50 | 345 | 40 | 275 | 20 | 30 | Raws li teev (zoo) |
9 | 90 | 620 | 70 | 483 | 15 | 25 | Raws li teev (zoo) |
11 | 35 | 240 | 20 | 138 | 24 | 30 | Raws li teev (zoo) |
12 | 70 | 483 | 50 | 345 | 18 | 25 | Raws li teev (zoo) |
16 | 50 | 345 | 40 | 275 | 20 | 30 | Raws li teev (zoo) |
17 | 35 | 240 | 25 | 170 | 24 | 30 | Raws li teev (zoo) |
23 | 120 | 828 | 110 | 759 | 10 | 25 | Beta-Annealed |
Titanium Chemical Composition
Qib 1 - Tsis siv neeg titanium
Qib 2 - Tsis siv neeg titanium
Qib 2H-Unalloyed titanium (Qib 2 nrog 58 ksi yam tsawg kawg nkaus UTS)
Qib 3 - Tsis siv neeg titanium
Qib 4 - Tsis siv neeg titanium
Qib 5 - Titanium alloy (6 feem pua aluminium, 4 feem pua vanadium)
Qib 7—Unalloyed titanium ntxiv rau 0.12 rau 0.25 feem pua palladium
Qib 7H—Unalloyed titanium ntxiv rau 0.12 rau 0.25 feem pua palladium (Qib 7 nrog 58 ksi yam tsawg kawg nkaus UTS)
Qib 9-Titanium alloy (3 feem pua ntawm txhuas, 2.5 feem pua vanadium)
Qib 11—Unalloyed titanium ntxiv rau 0.12 rau 0.25 feem pua palladium
Qib 12-Titanium alloy (0.3 feem pua molybdenum,0.8 feem pua npib tsib xee)
Qib 13-Titanium alloy (0.5 feem pua nickel, 0.05 feem pua ruthenium)
Qib 14-Titanium alloy (0.5 feem pua nickel, 0.05 feem pua ruthenium)
Qib 15-Titanium alloy (0.5 feem pua nickel, 0.05 feem pua ruthenium)
Qib 16—Unalloyed titanium ntxiv rau 0.04 txog 0.08 feem pua palladium
Qib 16H—Unalloyed titanium ntxiv rau 0.04 txog 0.08 feem pua palladiumm (Qib 16 nrog 58 ksi yam tsawg kawg nkaus UTS)
Qib 17—Unalloyed titanium ntxiv rau 0.04 txog 0.08 feem pua palladium
Qib 18-Titanium alloy (3 feem pua aluminium, 2.5 feem pua vanadium) ntxiv rau 0 04 mus rau 0.08 feem pua palladium
Qib 19-Titanium alloy (3% txhuas, 8% vanadium, 6% chromium, 4% zirconium, 4% molybdenum)
Qib 20-Titanium alloy (3 feem pua aluminium, 8 feem pua vanadium, 6 feem pua chromium, 4 feem pua zirconium, 4 feem pua molybdenum) ntxiv rau 0.04 feem pua -0.08 feem pua palladium
Qib 21-Titanium alloy (15 feem pua molybdenum, 3 feem pua aluminium, 2.7 feem pua niobium, 0.25 feem pua silicon)
Qib 23-Titanium alloy (6 feem pua aluminium, 4 feem pua vanadium nrog cov ntsiab lus qis qis, ELI)
Qib 24-Titanium alloy (6 feem pua aluminium, 4 feem pua vanadium) ntxiv rau 0 04 feem pua rau 0.08 feem pua palladium
Qib 25-Titanium alloy (6 feem pua aluminium, 4 feem pua vanadium) ntxiv rau 0.3 feem pua rau 0.8 feem pua nickel thiab 0.04 feem pua rau 0.08 feem pua palladium
Qib 26—Unalloyed titanium ntxiv rau 0.08 mus rau 0.14 feem pua ruthenium
Qib 26H—Unalloyed titanium ntxiv rau 0.
Qib 27—Unalloyed titanium ntxiv rau 0.08 txog 0.14 feem pua ruthenium
Qib 28-Titanium alloy (3 feem pua aluminium, 2.5 feem pua vanadium ntxiv rau 0 08–0.14 feem pua ruthenium)
Qib 29-Titanium alloy (6 feem pua aluminium, 4 feem pua vanadium, ntxiv qis qis, ELI ntxiv rau 0.08 mus rau 0.14 feem pua ruthenium)
Qib 30-Titanium alloy (0.3 feem pua cobalt, 0.05 feem pua palladium)
Qib 31-Titanium alloy (0.3 feem pua cobalt, 0.05 feem pua palladium)
Qib 32-Titanium alloy (5 feem pua aluminium, 1 feem pua tin, 1 feem pua zirconium, 1 feem pua vanadium, 0.8 feem pua molybdenum)
Qib 33-Titanium alloy (0.4 feem pua nickel, 0 015 feem pua palladium, 0.025 feem pua ruthenium, 0.15 feem pua chromium)
Qib 34-Titanium alloy (0.4 feem pua nickel, 0 015 feem pua palladium, 0.025 feem pua ruthenium, 0.15 feem pua chromium)
Qib 35-Titanium alloy (4.5 feem pua aluminium, 2 feem pua molybdenum, 1.6 feem pua vanadium, 0.5 feem pua hlau, 0.3 feem pua silicon)
Qib 36-Titanium alloy (45 feem pua niobium)
Qib 37-Titanium alloy (1.5 feem pua aluminium), thiab
Qib 38-Titanium alloy (4 feem pua ntawm txhuas, 2.5 feem pua vanadium, 1.5 feem pua hlau).
Piv txwv ntawm Titanium Casting Parts
Titanium Casting Pump Lub Cev
Titanium Casting Valve
Titanium yeeb nkab Union
Titanium yeeb nkab fittings
Titanium Parts Broach Broadhead sku 1
Titanium Casting Titanium Impeller sku 1
Titanium Casting Titanium Turbo Impeller
Titanium Fastener Tapered Socket Lub taub hau Ntsia Hlau
Titanium Flange
Titanium pob txha hloov
Titanium Tsheb kauj vab Pedal Spindle Axles
Titanium Tsheb kauj vab ceev tso qr-sku 1
Titanium Tsheb kauj vab ceev tso qr-sku 2
Titanium Tsheb kauj vab Rooj
Titanium Tsheb kauj vab Stem sku1
Titanium Broach Broadhead-sku2 (Kev Lag Luam Roj)
Titanium Tsheb kauj vab ncej
Titanium Casting Parts Titanium Valve Lub Cev
