PRODUCTS
Muaj nuj nqi
Khoom siv: | Ti-5Al-2Sn-2Zr-4Mo-4Cr |
Qhov tsos: | Cov khoom siv hlau hauv ntau hom |
Ceev: | 4.65 g / cm3 |
Theem Transformation Point: | 890 degree |
Tensile zog: | 1000 MPa |
Yield zog: | 1140 MPa |
UNS No.: | UNS R58650 |
Cov duab: | Customized |
Loj: | Raws li kev xav tau |
Ti-17 Titanium Alloy piav qhia
Ti-17 titanium alloy, tseem hu ua Ti-5Al-2Sn-2Zr-4Mo-4Cr alloy (UNS R58650), yog alpha-beta wrought alloy uas muaj lub zog tensile siab, zoo tawg toughness, zoo tawg loj hlob / qaug zog tsis kam, siab hardenability, thiab dav forging kub. Nws qhov siab tshaj plaws ua haujlwm kub ncav cuag 427 degree. Nws yog siv los ua lub zog siab sib sib zog nqus hardening alloy rau compressor discs thiab lwm yam khoom loj. Ti-17 Titanium Alloy tuaj yeem ua tiav hauv cheeb tsam beta lossis thaj tsam alpha plus beta. Ti-17 alloy muaj zog tensile thiab creeps ntau dua Ti-6Al{12}}V.
Ti-17 Titanium Alloy Specification
Ib feem pua | Ti-5Al-2Sn-2Zr-4Cr-4Mo (Ti17) |
Aluminium | 5 feem pua |
Ua ke carbon | - |
Titanium | Tshuav |
Molybdenum | 4 feem pua |
Silicon | 0.35 feem pua Max |
Chromium | 4 feem pua |
Tin | 2 feem pua |
Zirconium | 2 feem pua |
Acid Insoluble | - |
Ni plus Mn plus Cr plus Fe | - |
Deposition Factor | - |
Boron | 0.003 feem pua Max |
Cov pa roj carbon | 0.15 feem pua Max |
Tooj | - |
Hlau | 0.45 feem pua Max |
Magnesium | 0.25 feem pua Max |
Phosphorous | 0.035 feem pua Max |
Sulfur | 0.02 feem pua Max |
Tungsten | - |
Yttrium | - |
Hydrogen | 0.03 feem pua Max |
Nitrogen | 0.04 feem pua Max |
Oxygen | 0.10 feem pua Max |
Ti-17 Titanium Alloy Daim Ntawv Thov thiab Lwm Cov Kev Lag Luam
● Compressor discs
● Heavy seem forgings rau roj turbine cav Cheebtsam
● Cav qhov chaw fasteners thiab hydraulic kav
● Kev Tshawb Fawb & Kev Tshawb Fawb
● Roj & Roj
● Tsheb
● Lub dav hlau
● Kho mob
Cim npe nrov: ti -17 titanium alloy, Tuam Tshoj, lwm tus neeg, yuav, muag, ua nyob rau hauv Suav teb
