Muaj nuj nqi
Linear Formula: | W-Ni-Cu, W-Ni-Fe |
Khoom siv: | W-90 feem pua Ni-6 feem pua Cu-4 feem pua , W-92.5 feem pua Ni-4.5 feem pua Cu-3 feem pua , W{ {8}} feem pua Ni-3.5 feem pua Cu-1.5 feem pua W-90 feem pua Ni-7 feem pua Fe-3 feem pua , W-92.5 feem pua Ni-5.25 feem pua Fe-2.25 feem pua , W-95 feem pua Ni-3.5 feem pua Fe-1.5 feem pua , W-97 feem pua Ni-2.1 feem pua Fe-0.9 feem pua |
Nto: | Xaus txoj siav, Milling, Sib Tsoo |
Loj: | Txoj kab uas hla 2 ~ 320mm, Ntev 2 ~ 600mm |
Tungsten Alloy Qws thiab Bar Description
Tungsten alloy pas nrig thiab bar muaj ntau yam zoo heev xws li siab ceev, siab melting point, me me ntim, siab hnav tsis kam, siab hardness, siab tensile zog, siab elongation, thiab kub-resistant. Tungsten alloy cov khoom siv dav siv hauv kev lag luam.
Tungsten alloy pas nrig yog npaj los ntawm thawj zaug sib xyaw tungsten hmoov nrog lwm cov hmoov hlau, nias nws, thiab tom qab ntawd sintering nws mus rau hauv ib qho khoom tsis tiav. Tom qab cov khoom tsis tiav ib nrab yog raug rau swaging thiab txiav, tungsten alloy pas nrig yog thaum kawg tsim. Cov tungsten alloy rods tuaj yeem ua rau txhua qhov ntev raws li cov neeg siv khoom xav tau, qhov saum npoo yog du, thiab txoj kab uas hla yog ntau tshaj 2 hli. Tungsten alloy pas nrig tuaj yeem ua tiav rau hauv cov duab hollow. Lub hollow raj phab ntsa yog nyob rau hauv 3 mm. Tshwj xeeb ntev thiab cov qauv tuaj yeem ua tiav raws li tus neeg siv khoom xav tau.
SSC muab forged tungsten alloys, dov tungsten alloys, swagged tungsten alloys, tsis muaj kev siv ntxiv peb hu ua lawv li semifinished tungsten alloys. Cov ntaub ntawv tuaj yeem npog tag nrho cov tungsten hnyav alloys, feem ntau yog tungsten-nickel-hlau alloy thiab tungsten-nickel-tooj liab alloy. Forged tungsten alloys muaj xws li ingot, pas nrig, bar, thaiv, thiab phaj. Dimensions rau forged qhov chaw yog ib txwm loj, chav tsev qhov hnyav yuav mus txog rau txhiab phaus. Rolled tungsten alloys suav nrog phaj, ntawv, thiab ntawv ci, thickness xws li 0 05mm txog 6.0mm. Lawv feem ntau yog siv los tiv thaiv qhov chaw hauv kev kho mob thiab hluav taws xob kev lag luam. SSC muab semifinished tungsten alloys khoom nrog rau tungsten alloys fasteners uas siv los ua ke.
Tungsten Alloy Qws thiab Bar Specification
Hom | Qhov ceev g / cm3 | Tensile zog | Elongation | HRC |
85W-10.5Ni-4.5Fe | 15.8-16.0 | 700-1000 | 20-33 | 20-30 |
90W-7Ni-3Fe | 16.9-17.1 | 700-1000 | 20-33 | 24-32 |
90W-6Ni-4Fe | 16.7-17.0 | 700-1000 | 20-33 | 24-32 |
91W-6Ni-3Fe | 17.1-17.3 | 700-1000 | 15-28 | 25-30 |
92W-5Ni-3Fe | 17.3-17.5 | 700-1000 | 18-28 | 25-30 |
92.5W-5Ni-2.5Fe | 17.4-17.6 | 700-1000 | 25-30 | 25-30 |
93W-4Ni-3Fe | 17.5-17.6 | 700-1000 | 15-25 | 26-30 |
93W-4.9Ni-2.1Fe | 17.5-17.6 | 700-1000 | 15-25 | 26-30 |
93W-5Ni-2Fe | 17.5-17.6 | 700-1000 | 15-25 | 26-30 |
95W-3Ni-2Fe | 17.9-18.1 | 700-900 | 8-15 | 25-35 |
95W-3.5Ni-1.5Fe | 17.9-18.1 | 700-900 | 8-15 | 25-35 |
96W-3Ni-1Fe | 18.2-18.3 | 600-800 | 6-10 | 30-35 |
97W-2Ni-1Fe | 18.4-18.5 | 600-800 | 8-14 | 30-35 |
98W-1Ni-1Fe | 18.4-18.6 | 500-800 | 5-10 | 30-35 |
90W-6Ni-4Cu | >17.0-17.2 | 600-800 | 4-8 | 25-35 |
93W-5Ni-2Cu | 17.5-17.6 | 500-600 | 3-5 | 25-35 |
Daim ntawv thov thiab lwm yam lag luam rau Tungsten Alloy Qws thiab Bar
● Tus tswv cuab qhov hnyav rau kev tswj thiab faib qhov hnyav
● Cov ntaub thaiv hluav taws xob
● Cov khoom siv tub rog
● Vuam pas nrig
● Pwm
● Darts
● Cov koom haum ntaus golf
● Vacuum electronics
● High-temperature resistant qhov chaw
● Kho mob
● Tub rog
● Tooling
Cim npe nrov: tungsten alloy pas nrig thiab bar, Tuam Tshoj, lwm tus neeg, yuav, muag, ua nyob rau hauv Suav teb
