Muaj nuj nqi
CAS Nr .: | 7440-25-7 |
Txuj: | ASTM B 364-92 |
Purity: | Ntau dua lossis sib npaug li 99.9 feem pua lossis 99.95 feem pua |
Loj: | Txoj kab uas hla 70-195 mm, Length Tsawg dua lossis sib npaug li 1600 mm |
Khoom Qib: | R05200, unalloyed tantalum, electron-beam rauv los yog nqus-arc yaj, los yog ob qho tib si R05400, unalloyed tantalum, hmoov-metallurgy consolidation. |
Tantalum Ingot Description
Ingots feem ntau yog cov ntawv hlau uas tsis tshua muaj nqi thiab muaj txiaj ntsig zoo hauv kev siv dav dav.
SSC tshwj xeeb hauv kev tsim cov kev cai sib xyaw rau kev lag luam thiab kev tshawb fawb daim ntawv thov thiab rau cov cuab yeej tshiab.
Kev npaj ntawm tantalum thiab tantalum alloys feem ntau yog ua nyob rau hauv lub cub hluav taws xob hluav taws xob. Txhawm rau kom tau txais cov khoom sib xws hauv lub tshuab hluav taws xob hluav taws xob, lub tshuab nqus tsev arc melting yog nqa tawm. Tag nrho cov tantalum thiab tantalum alloys yuav raug cam khwb cia rau hauv lub cub hluav taws xob hluav taws xob, xws li seb lub tshuab nqus tsev arc melting (VAR) siv tib lub sijhawm, thiab pes tsawg lub sij hawm melting yog txiav txim siab raws li kev siv cov khoom tshwj xeeb.
Tailor-made tantalum alloy ingots, xws li tantalum tungsten alloy, tantalum niobium alloy kuj muaj nyob ntawm SSC.
Tshuaj muaj pes tsawg leeg
Lub ntsiab | C | O | N | H | Fe | Mo | Nb | Ni | Si | Ti | W |
R05200 (feem pua, Max) | 0.01 | 0.015 | 0.01 | 0.0015 | 0.01 | 0.02 | 0.1 | 0.01 | 0.005 | 0.01 | 0.05 |
R05400 (%) | 0.01 | 0.03 | 0.01 | 0.0015 | 0.01 | 0.02 | 0.1 | 0.01 | 0.005 | 0.01 | 0.05 |
Tantalum Ingot Daim Ntawv Thov thiab Lwm Yam Kev Lag Luam
● Cov khoom siv hauv chav kuaj
● Hloov rau platinum
● Kev tsim cov superalloys thiab electron-beam melting
● Metallurgy
● Machinery
● iav
● Ceramic
● Superalloy additive nyob rau hauv nickel-raws li alloys
● Sputtering lub hom phiaj
Chemical Identifiers
Linear Formula | Ta |
MDL Number | TIAB SA 00011252 |
EC No. | 231-135-5 |
Beilstein/Reaxys No. | N/A |
Pubchem CID | 23956 |
SMILES | [Ta] |
InchI ID nkag mus | InChI=1S/Ta |
InchI Key | GUVRBAGPIYLISA-UHFFFAOYSA-N |
Tantalum Ingot Properties (Theoretical)
Molecular Luj | 180.94 |
Qhov tshwm sim | Silvery-grey khoom |
Melting Point | 3017 degree |
Boiling Point | 5 458d |
Qhov ntom | 16.69 g / cm²3(20 degree) |
Solubility hauv H2O | N/A |
Crystal Phase / Qauv | : body-centered cubic (bcc) / : tetragonal |
Hluav taws xob Resistivity | 131 nΩ·m (20 degree) |
Electronegativity | 1.5 Pauling |
Kub ntawm Fusion | 36.57 kJ/mol |
Kub ntawm Vaporization | 753 kJ / mol |
Poisson tus ratio | 0.34 |
Tshwj xeeb kub | 140 J/kg · K |
Thermal conductivity | 57.5 W/m·K |
Thermal Expansion | 6.3 µm/m·K |
Vickers Hardness | 870-1200 MPa |
Young's Modulus | 186 GPA |
Cim npe nrov: tantalum ingot, Tuam Tshoj, lwm tus neeg, yuav, muag, ua nyob rau hauv Suav teb
