Muaj nuj nqi
Linear Formula: | Y2O3 • ZrO2 |
Khoom siv: | Yttria Stabilized Zirconia |
Qhov tsos: | Hmoov, granules, los yog khoom nyob rau hauv ntau hom |
Yttria Stabilized Zirconia piav qhia
Yttria stabilized zirconia (YSZ / YTZ), tseem hu ua yttria zirconia, yttria stabilized zirconium oxide, yog cov khoom siv hluav taws xob muaj zog tshaj SSC. YSZ yog ib theem tetragonal nkaus xwb, cov khoom zoo. Cov khoom siv no muaj lub zog siab tshaj plaws ntawm tag nrho cov khoom siv zirconia.
SSC tsim YSZ hmoov los ntawm tus kheej-propagating hydrolysis txheej txheem. Raws li cov ntsiab lus sib txawv ntawm Y2O3, peb tuaj yeem tsim cov hmoov YSZ sib txawv. Cov khoom lag luam ib txwm yog 3 mol feem pua YSZ hmoov-raws li, muab faib ua cov hmoov sib xyaw thiab cov hmoov tsis sib xyaw nyob ntawm cov neeg siv khoom xav tau. Cov khoom siv lub cev tuaj yeem ua tau raws li cov neeg siv khoom sib txawv rau kev nias qhuav, isostatic nias, txhaj tshuaj, casting, txhaj tshuaj molding, thiab plam casting thiab lwm yam.
Yttria stabilized zirconia yog muaj nyob rau hauv ib nrab thiab tag nrho stabilized. Ib nrab stabilized zirconia (PSZ) yog ib qho sib xyaw ntawm zirconia polymorphs, vim tsis txaus cubic theem-forming oxide (stabilizer) tau ntxiv thiab cubic plus metastable tetragonal ZrO2 sib tov yog tau. Feem ntau thiab siv dav PSZ yog 3 mol feem pua ntawm yttria stabilized zirconia. Nws muaj 3 mol feem pua yttria (Y2O3), 5.2 ± 0.2 feem pua hauv qhov hnyav.
Peb muaj pes tsawg leeg rau YSZ suav nrog 3 feem pua, 5 feem pua thiab 8 feem pua molar ytria. Qhov siab tshaj plaws oxygen ion conductivity tshwm sim nrog kwv yees li 10 mol feem pua Y2O3 ntxiv.
Yttria Stabilized Zirconia Hmoov Specifications
Khoom npe | Purity | Lwm yam khoom | Loj Loj |
Yttria (3 mol feem pua) Stabilized Zirconia | Zr(Hf)O2 94.5 feem pua ; | D50 = 0.5-0.8 µm; | 100 kg |
Yttria (3 mol feem pua) Stabilized Zirconia | Zr(Hf)O2 94.5 feem pua ; | D50 < 1.0=""> | 100 kg |
Yttria (5 mol feem pua) Stabilized Zirconia | Zr(Hf)O2 91 feem pua ; | D50= 0 5-1 µm; Qhov chaw tshwj xeeb< 10="" m=""> | 100 kg |
Yttria (8 mol feem pua) Siab Stabilized Zirconia | Zr(Hf)O2 85.5 feem pua ; | D50 = 0.5 - 1.0 µm; Specific Surface Area >15 m2/gm. | 100 kg |
Yttria (8 mol feem pua) Siab Stabilized Zirconia | Zr(Hf)O2 85.5 feem pua ; | D{0}}5 - 1.0 µm; Qhov chaw tshwj xeeb< 10=""> | 100 kg |
Peb Yttria Stabilized Zirconia Khoom
● Zirconia Mortar & Pestle
● Zirconia Phaj
● Zirconia Crucible
● Zirconia Txiav Hniav
● Zirconia Tube
● Zirconia Plunger
● Zirconia lauj kaub / thawv
● Zirconia Nplhaib
● Zirconia qws
● Zirconia Pob Valve
● Zirconia Sib Tsoo Media
Dimensions ntawm Peb Cov Khoom Siv Zirconia Ceramic
Khoom npe | Kev piav qhia |
Zirconia (YSZ) Sib Tsoo Media | Khoom siv: 94.6% ZrO2 ntxiv rau 5.25% Y2O3 |
Yttria Stabilized Zirconia Jar nrog Lub hau | Khoom siv: 94.7% ZrO2 ntxiv rau 5.2% Y2O3 |
Zirconia Mortar thiab Pestle | Zirconia Mortar 60 x 50 x 20 w/h Pestle |
Zirconia (YSZ) Tube | {{0}}.375" OD x 0.25" ID x 8" L |
Zirconia Crucible (ZrO2 Crucible) | Kwv yees li. Peev xwm: 2-300 ml |
Lwm yam (Plate, Txiav hniav, Plunger, Ntiv nplhaib, Qws, Pob Valve, thiab lwm yam) | Customized |
Specification ntawm Yttria (3 mol feem pua) Stabilized Zirconia
Kev sib xyaw | wt feem | 94.5% ZrO2, 5.2 ± 0.2% Y2O3 |
Tshwj xeeb ceev | g/cm3 | Ntau dua lossis sib npaug rau 5.95 |
Hardness (HV) | GPa | >12 |
Thermal expansion coefficient (20-400 degree) | X10-6/k | 11 |
Elastic modulus | GPa | 205 |
Fracture toughness | MPa·m 1/2 | >9 |
Khoov zog | MPa | >1150 |
Cov qoob loo loj | μm | <> |
Thermal conductivity | w/(m·k) | 3 |
Kev nqus dej: | feem pua | <> |
Hluav taws kub kub: | degree | 1550 |
Compression zog: | MPa | 25000 |
Breaking tenacity: | Mpa•m1/2 | 6-8 |
Kub expansion coefficient: | 9.5x 10-6 / degree |
Nta ntawm Yttria Stabilized Zirconia (YSZ) Cov Khoom
● Super hardness
● High ceev
● Siab khoov lub zog thiab tawg tenacity
● Tsawg thermal conductivity (20 feem pua ntawm alumina)
● Zoo tshuaj ruaj khov
● Resistance rau molten hlau
● Siab hnav-tiv taus
● High puas toughness
● Zoo corrosion kuj
● Kub siab kam rau ua
● Cov rwb thaiv tsev zoo
● Muaj zog txhua yam
● Zoo polishing nto
● Precision kam rau ua
Yttria Stabilized Zirconia Daim Ntawv Thov thiab Lwm Cov Kev Lag Luam
● Cov qauv ceramics
● Plasma txheej
● Cov hniav yas
● Dav hlau tshuab
● Thermal barrier txheej hauv roj turbines
● Electroceramic
● Hloov cov hlau
● Insulating rings nyob rau hauv cov txheej txheem thermal
● Precision shafts thiab axles nyob rau hauv siab hnav ib puag ncig
● Hnav cov ntaub thaiv npog
● Thermocouple tiv thaiv raj
● Sandblasting nozzles
● Cov khoom siv refractory
● Extrusion tuag
● Bushings thiab kaus mom
● Fiber optic ferrules thiab lub tes tsho
● Riam thiab hniav
● Roj cell qhov chaw
● Bearings & rollers
● Vuam nozzles & pins
● Laser qhov chaw
● Gas igniters
● Hluav taws xob rwb thaiv tsev
● Ceramic guiders
● Oxygen sensors
● Cov khoom siv kho mob thiab phais
● Mechanical seals
● Additive Manufacturing
● 3D Luam Ntawv
● Kev Kho Hniav
● Roj Cells Oxides
● Lub Ntiaj Teb tsis tshua muaj
● Refractory Ceramics
● Kev Tshawb Fawb & Kev Tshawb Fawb
