Titanium Zirconium Molybdenum

Titanium Zirconium Molybdenum (TZM) yog ib qho kev ua haujlwm siab refractory alloy uas nthuav tawm cov khoom siv zoo heev thiab thermal. Nws yog kev sib xyaw ntawm 0.5 feem pua ​​​​titanium, 0.08 feem pua ​​​​zirconium, thiab 0.01 feem pua ​​carbon nrog cov seem yog molybdenum. Qhov sib ntxiv ntawm titanium thiab zirconium txhim kho cov alloy lub zog, toughness, thiab creep kuj, thaum carbon txhim kho nws cov kev ua haujlwm kub.

Nta:

● Lub zog thiab tawv tawv ntawm qhov kub thiab txias

● Zoo heev creep kuj

● Tsawg thermal expansion coefficient

● High thermal conductivity

● Zoo corrosion kuj

● High melting point (2610 degree)

● Zoo weldability thiab machinability

Qib:

TZM muaj nyob rau hauv ntau qib, suav nrog:

● TZM 364: Qhov no yog qib siv ntau tshaj plaws thiab muaj 0.5 feem pua ​​​​titanium, 0.08 feem pua ​​​​zirconium, thiab 0.01 feem pua ​​carbon.

● TZM 365: Qib no muaj 0.5 feem pua ​​​​titanium, 0.08 feem pua ​​​​zirconium, thiab 0.02 feem pua ​​carbon.

● TZM 366: Qib no muaj 0.5 feem pua ​​​​titanium, 0.08 feem pua ​​​​zirconium, thiab 0.04 feem pua ​​carbon.

Daim ntawv:

TZM muaj ntau hom ntawv, suav nrog:

Bars:

● Txoj kab uas hla: 0.2 nti rau 4 ntiv tes (5mm txog 100mm)

● Ntev ntev: 4 nti rau 118 nti (100mm txog 3000mm)

● Kev kam rau siab: ntxiv /- 0.004 nti rau ntxiv /- 0.04 ntiv tes, nyob ntawm txoj kab uas hla (ntxiv rau /- 0.1mm rau ntxiv /- 1mm, nyob ntawm ntawm diam)

Cov ntawv:

● Thickness range: {{0}}.004 ntiv tes rau 2 ntiv tes (0.1mm txog 50mm)

● Dav ntau yam: 4 nti rau 39 ntiv tes (100mm txog 1000mm)

● Ntev ntev: 4 nti txog 79 ntiv tes (100mm txog 2000mm)

● Kev kam rau siab: ntxiv /- 0.004 nti rau ntxiv /- 0.04 ntiv tes, nyob ntawm qhov tuab thiab dav (ntxiv rau /- 0.1mm rau ntxiv /- 1mm , nyob ntawm thickness thiab dav)

Daim hlau:

● Thickness range: 0.2 nti mus rau 4 ntiv tes (5mm txog 100mm)

● Dav ntau yam: 4 nti rau 39 ntiv tes (100mm txog 1000mm)

● Ntev ntev: 4 nti rau 118 nti (100mm txog 3000mm)

● Kev kam rau siab: ntxiv /- 0.004 nti rau ntxiv /- 0.04 ntiv tes, nyob ntawm qhov tuab thiab dav (ntxiv rau /- 0.1mm rau ntxiv /- 1mm , nyob ntawm thickness thiab dav)

Qws:

● Txoj kab uas hla: 0.04 ntiv tes rau 2 ntiv tes (1mm txog 50mm)

● Ntev ntev: 4 nti rau 118 nti (100mm txog 3000mm)

● Kev kam rau siab: ntxiv /- 0.004 nti rau ntxiv /- 0.04 ntiv tes, nyob ntawm txoj kab uas hla (ntxiv rau /- 0.1mm rau ntxiv /- 1mm, nyob ntawm ntawm diam)

Cov Hlau:

● Txoj kab uas hla: {{0}} 004 ntiv tes rau 0.4 ntiv tes (0.1mm txog 10mm)

● Ntev ntev: 4 nti rau 118 nti (100mm txog 3000mm)

● Kev kam rau siab: ntxiv /- 0.0002 nti rau ntxiv /- 0.004 ntiv tes, nyob ntawm txoj kab uas hla (ntxiv rau /- 0.005mm rau ntxiv /- 0.1mm, nyob ntawm txoj kab uas hla)

Txoj kev tsim khoom:

TZM yog tsim los siv cov txheej txheem hmoov metallurgy uas koom nrog kev sib xyaw cov ntsiab lus hauv cov hmoov hmoov thiab tom qab ntawd sintering lawv ntawm qhov kub thiab txias hauv lub tshuab nqus tsev lossis hydrogen. Cov txiaj ntsig TZM alloy yog tom qab ntawd forged, dov, lossis kos rau hauv qhov xav tau.

Daim Ntawv Thov & Lwm Cov Kev Lag Luam:

TZM muaj ntau daim ntawv thov hauv ntau qhov kev lag luam, suav nrog:

● Aerospace: TZM yog siv nyob rau hauv kev lag luam aerospace rau lub cav qhov chaw, tso pa tawm, thiab lwm yam kev siv kub.

● Kev Tiv Thaiv: TZM yog siv rau hauv kev lag luam tiv thaiv rau cov khoom siv foob pob hluav taws, foob pob hluav taws lub cev muaj zog, thiab lwm yam kev siv zog siab.

● Nuclear: TZM yog siv rau hauv kev lag luam nuclear rau roj rods, reactor Cheebtsam, thiab lwm yam kev siv kub.

● Kev Kho Mob: TZM yog siv rau hauv kev kho mob kev lag luam rau kev cog qoob loo, cov cuab yeej phais, thiab lwm yam kev siv zog siab.

● Cov Khoom Siv Hluav Taws Xob: TZM yog siv rau hauv kev lag luam hluav taws xob rau cov dab dej kub, hluav taws xob tiv tauj, thiab lwm yam kev siv hluav taws xob kub.

Health & Safety Information:

TZM suav tias yog kev nyab xeeb rau kev tuav thiab siv. Txawm li cas los xij, zoo li txhua yam hlau, nws tuaj yeem tso cov plua plav lossis pa taws thaum ua haujlwm lossis tuav, uas tuaj yeem tsim kev puas tsuaj yog tias nqus tau. Yog li, kev ntsuas kev nyab xeeb tsim nyog yuav tsum tau ua thaum tuav lossis ua TZM, suav nrog kev siv cov cuab yeej tiv thaiv tus kheej (PPE), xws li hnab looj tes, tsom iav kev nyab xeeb, thiab lub ntsej muag plua plav.

Peb qhov zoo:

● Cov khoom zoo TZM

● Cov nqi sib tw

● Kev xa khoom raws sij hawm

● Kev pabcuam zoo rau cov neeg siv khoom

● Customized solutions kom tau raws li koj cov kev xav tau tshwj xeeb

● Cov kws tshaj lij kev txhawb nqa

FAQs:

Q: Lub melting point ntawm TZM yog dab tsi?

A: Lub melting point ntawm TZM yog 2610 degree.

Q: Qhov txawv ntawm TZM thiab ntshiab molybdenum yog dab tsi?

A: TZM muaj me me ntawm titanium, zirconium, thiab carbon, uas txhim kho nws lub zog, toughness, thiab creep resistance piv rau cov ntshiab molybdenum.

Q: Puas yog TZM weldable?

A: Yog, TZM yog vuam siv cov txheej txheem vuam tsoos, xws li TIG lossis laser vuam.

Q: Lub txee lub neej ntawm TZM yog dab tsi?

A: TZM muaj lub neej txee tsis kawg yog tias khaws cia zoo. Txawm li cas los xij, nws raug pom zoo kom khaws cia rau hauv qhov chaw qhuav, txias, thiab huv si kom tsis txhob muaj kev sib kis lossis oxidation. Nws kuj raug pom zoo kom khaws cia rau hauv nws qhov qub ntim lossis qhwv hauv cov khoom siv tiv thaiv kom tsis txhob muaj kev puas tsuaj thaum khaws cia lossis kev thauj mus los.
