Muaj nuj nqi
Linear Formula: | MoCu |
Qhov tsos: | Cov khoom siv hlau |
Cov duab: | Sheet, Phaj, Qws, Bar lossis Customized |
Molybdenum Copper Alloy Description
Molybdenum tooj liab alloy yog pseudo-alloy ua los ntawm tooj liab thiab molybdenum uas tsis sib zog ua ke. Copper clad molybdenum ua tau zoo ntawm tooj liab thiab molybdenum uas yog oxidation thiab corrosion-resistant, ua tau zoo nyob rau hauv high-temperature daim ntaub ntawv.
Molybdenum tooj liab yog ib qho ntawm ntau cov hlau alloys muag los ntawm SSC. SSC cov khoom siv hlau muaj nyob rau hauv ntau hom xws li hmoov, tuav, ingots, ribbons, xov hlau, nplooj ntawv, sputtering lub hom phiaj, foils, thiab cov duab kev cai nyob rau hauv ob qho tib si tus qauv thiab cov neeg siv khoom tshwj xeeb cov khoom xyaw. Peb cov engineers tuaj yeem muab kev taw qhia hauv kev xaiv cov hlau alloy raws li qhov xav tau ntawm daim ntawv thov. Thov thov cov lus hais saum toj no kom tau txais cov ntaub ntawv nqi raws li koj qhov tshwj xeeb.
Peb tsim ntau yam ntawm molybdenum alloy zeb khoom siv hmoov metallurgy (PM) txoj kev. Qhov muaj ntawm cov khoom los ntawm cov txheej txheem no ua rau cov neeg siv ntau txoj hauv kev xaiv cov khoom siv los ua kom tau raws li lawv cov kev thov tshwj xeeb. Mo alloy zeb khoom yog muaj los ntawm ob txheej txheem xws li forging billets, bar, pas nrig, ntawv, phaj thiab ntawv ci. Tag nrho cov ntaub ntawv nyob rau hauv lub hauv paus yog tib yam loj npaum li cov ntshiab molybdenum tshwj tsis yog cov ntawv ci nyias.
Coefficient ntawm thermal expansion (CTE) ntawm tooj liab molybdenum tuaj yeem raug kho los ntawm kev kho cov muaj pes tsawg leeg, uas yog tib yam nrog tungsten tooj liab composites. MoCu yog qhov sib zog dua li tungsten cooper, uas ua rau nws tsim nyog rau kev siv aerospace.
Qhov tseem ceeb tshaj plaws ntawm kev siv tooj liab molybdenum yog cov dab dej kub rau cov khoom siv hluav taws xob. Dhau li ntawm MoCu thiab WCu (tungsten tooj liab) cov dab dej kub, peb tuaj yeem muab cov molybdenum ntshiab, Cu-Mo-Cu cua sov dab dej, Mo-Cu-Mo, Cu-MoCu-Cu qhov chaw thiab Mo-CuMo-Mo.
Mo-Cu Kub Sinks Specification
Lub cev muaj zog | mo85cu15 | Mo80Cu20 | m70cu 30 | mo60cu40 | Mo50Cu50 |
Kev sib xyaw (wt feem pua Mo Cu: balance) | 85 feem pua | 80 feem pua | 70 feem pua | 60 feem pua | 50 feem pua |
Qhov ceev ntawm 20 degree (g / cm3) | 10.0 | 9.9 | 9.8 | 9.6 | 9.5 |
CTE ntawm 20 degree (10-6/K) | 6.8 | 7.2 | 9.1 | 10.3 | 11.5 |
Thermal conductivity (W / mK) | 165 | 175 | 195 | 215 | 250 |
Cov cua kub tshwj xeeb ntawm 100 degree (J / kgK) | 275 | - | 301 | 310 | 323 |
Hluav taws xob conductivity ntawm 20 degree (MS / m) | 18.5 | 19.8 | 22.3 | 24.8 | 27.3 |
Young's Modulus ntawm 20 degree (Gpa) | 248 | 241 | 225 | - | 172 |
Flexural zog (MPa) | 1,138 | 1,103 | - | - | - |
Vicker's Hardness (HV 10) | - | - | 170 | - | 150 |
Cu-Mo-Cu (CMC) Kub Sinks Specification
Cu: Mo: Cu (Thick ratio) | Qhov ceev (g / cc) | Coefficient ntawm Thermal Expansion (10-6/K) | Thermal conductivity (W/m·K), xy direction | Thermal conductivity (W/m·K), xz kev taw qhia |
1:1:1 | 9.4 | 9.4 | 300~310 | 240~250 |
1:2:1 | 9.6 | 7.7 | 260~270 | 210~220 |
1:3:1 | 9.7 | 6.9 | 230~240 | 190~200 |
1:4:1 | 9.8 | 6.2 | 210~220 | 170~180 |
13:74:13 | 9.9 | 5.8 | 190~200 | 160~170 |
Cu-Mo70Cu-Cu (CPC) Kub Sinks Specification
Cu-Mo70Cu-Cu (Thick ratio) | Qhov ceev (g / cc) | Coefficient ntawm Thermal Expansion (10-6/K) | Thermal conductivity (W / m · K) | ||
Phaj kev taw qhia | Kev taw qhia tuab | Phaj kev taw qhia | Kev taw qhia tuab | ||
1:4:1 | 9.46 | 7.2 | 9.0 | 250-300 | 210-250 |
Molybdenum Copper Alloy Daim Ntawv Thov thiab Lwm Yam Kev Lag Luam
● Lub tshuab nqus tsev tiv tauj
● Conductive heat dissipation Cheebtsam
● Cov khoom siv ntsuas
● Cov foob pob hluav taws uas siv los ntawm qhov kub thiab txias me ntsis
● Cov khoom siv kub-kub ntawm cov cuaj luaj thiab cov khoom siv hauv lwm yam riam phom xws li cov kab txuas ntxiv
● Khoom sealing
● Sliding kev sib txhuam reinforcing tav
● Dej-txias electrode taub hau nyob rau hauv high-temperature furnaces
● Electro-machined electrodes
● Metallurgy
● Aerospace
● Kev Tshawb Fawb & Kev Tshawb Fawb
Chemical Identifiers
Linear Formula | MoCu |
MDL Number | N/A |
EC No. | N/A |
Pubchem CID | 57448858 |
IUPAC npe | tooj liab; molybdenum |
SMILES | [Cu] [Mo] |
InchI ID nkag mus | InChI=1S/Cu.Mo |
InchI Key | WUUZKBJEUBFVMV-UHFFFAOYSA-N |
Molybdenum Copper Alloy Properties (Theoretical)
Compound Formula | MoCu |
Molecular Luj | 159.496 |
Qhov tshwm sim | Hlau khoom nyob rau hauv ntau yam ntaub ntawv (phaj, ntawv, daim, kev cai qhov chaw) |
Melting Point | N/A |
Boiling Point | N/A |
Qhov ntom | 9. 3-10 {2}} g/cm3 |
Solubility hauv H2O | N/A |
Hluav taws xob Resistivity | 3.8 x 10-6Ω·cm |
Thermal conductivity | 195-250 W/m·K |
Thermal Expansion | 6. 8-10.3 µm/m- degree |
Exact Mass | 160,835 g / mol |
Monoisotopic pawg | 160,835 g / mol |
