Indium Zinc Oxide

Indium Zinc Oxide (IZO) yog pob tshab conductive oxide (TCO) uas yog tsim los ntawm indium oxide, zinc oxide, thiab dopant ntsiab. Nws yog cov khoom siv pob tshab uas muaj cov khoom siv hluav taws xob zoo heev thiab feem ntau yog siv los hloov Indium Tin Oxide (ITO) hauv ntau yam kev siv hluav taws xob.

Nta:

● High hluav taws xob conductivity

● Siab pob tshab

● Kev ruaj ntseg zoo nyob rau hauv ntau yam ib puag ncig

● Tsawg tsis kam

● Customizable dopant concentrations

● Tau tshaj nrog ntau yam kev tso nyiaj tso tawm

Qib:

● Purity: 99.99 feem pua

● Muaj pes tsawg leeg: In2O3:ZnO (90:10, 95:5, 97:3)

● Customizable dopant concentrations

Daim ntawv:

● Sputtering targets (Density: >6. 0 g/cm³, Grain loj:<100 µm, Surface finish: Ra ≤ 0.8 µm, Dimensions: Customizable based on customer requirements)

● Hmoov (Particle loj:<5 µm, <10 µm, <20 µm, or customizable based on customer requirements, Specific surface area: 5-15 m²/g)

● Nyias films (Thickness: 50-300} nm, customizable raws li tus neeg yuav tsum tau muaj, Sheet resistance:<15Ω/sq, Transmittance: >80 feem pua ​​​​ntawm 550 nm, Tshaj tawm cov txheej txheem: sputtering, electron beam evaporation, pulsed laser deposition, thiab lwm yam txheej txheem nyias zaj duab xis deposition)

● Customizable duab thiab ntau thiab tsawg

Txoj kev tsim khoom:

Indium Zinc Oxide feem ntau yog tsim los ntawm cov txheej txheem sputtering, uas indium oxide, zinc oxide, thiab dopant ntsiab yog co-sputtered mus rau ib tug substrate. Qhov tshwm sim IZO zaj duab xis tuaj yeem raug muab tshem tawm los txhim kho nws cov khoom siv hluav taws xob thiab kho qhov muag.

Daim Ntawv Thov & Lwm Cov Kev Lag Luam:

● Vaj huam sib luag tiaj tus

● Kov cov ntxaij vab tshaus

● Solar cells

● Organic light-emitting diodes (OLEDs)

● Nyias-film transistors (TFTs)

● Cov qhov rais ntse

● Automotive zaub

● Aerospace qhia

● Cov khoom siv kho mob

● Lwm yam kev siv hluav taws xob

Health & Safety Information:

Indium Zinc Oxide feem ntau suav hais tias muaj kev nyab xeeb rau kev tuav thiab siv hauv kev siv hluav taws xob. Txawm li cas los xij, nws yog ib qho tseem ceeb kom ua raws li kev tiv thaiv kev nyab xeeb kom raug thaum tuav IZO hmoov lossis sputtering lub hom phiaj. Cov kev ceev faj no suav nrog hnav khaub ncaws tiv thaiv tsim nyog, hnab looj tes, thiab tiv thaiv qhov muag, thiab tsis txhob noj lossis nqus cov khoom.

Peb qhov zoo:

● Customizable dopant concentrations

● Ntau hom ntawv thiab ntau thiab tsawg

● Cov nqi sib tw

● Cov khoom lag luam zoo nrog kev ua haujlwm zoo ib yam

● Lub sijhawm xa khoom sai

● Teb cov neeg siv khoom

FAQs:

Q: Puas yog Indium Zinc Oxide tuaj yeem siv los hloov Indium Tin Oxide?

A: Yog, IZO feem ntau yog siv los hloov ITO hauv ntau daim ntawv thov hluav taws xob vim nws cov hluav taws xob hluav taws xob siab thiab pob tshab.

Q: Dab tsi yog qhov tuab ntawm IZO nyias zaj duab xis?

A: Lub thickness ntawm IZO nyias zaj duab xis tuaj yeem sib txawv nyob ntawm seb cov ntawv thov tshwj xeeb thiab cov neeg siv khoom xav tau. Nws feem ntau yog nyob rau hauv qhov ntau ntawm 50-300 nm.

Q: Cov txheej txheem tso nyiaj dab tsi tau tshaj nrog IZO?

A: IZO tuaj yeem tso tau siv ntau hom kev kawm, suav nrog sputtering, electron beam evaporation, thiab pulsed laser deposition. Cov txheej txheem tshwj xeeb siv yuav nyob ntawm cov neeg siv khoom xav tau thiab cov ntawv thov tshwj xeeb.

Cim npe nrov: indium zinc oxide, Tuam Tshoj, lwm tus neeg, yuav, muag, ua nyob rau hauv Suav teb
